LED PROJECTION LAMP RL-SD200
规格参数消耗功率: 350W (根据实际现场需求定制方案)
防水等级: IP54输入
电压: AC220V
效果: 3D动画效果或单色效果可以定制效果
工作温度: -20度-45度
出光类型:角度可调
灯体材质:高强度铝型材，外表做喷涂或喷砂氧化处(白色、深灰、黑色可选)
产品尺寸: 615*215*536(mm)
净重: 30.6K
GSpecificationsPower consumption: 350W(customized according to actualsite requirements)
Waterproof rating: IP54
Input voltage: AC220V
Effect: 3D animation effect or monochrome effect can be customized
Working temperature: -20 degrees - 45 degrees
Light type: adjustable angle
Lamp body material: high-strength aluminum profile, surface forspraying or sandblasting oxidation (whiteColor, dark gray, black optional)
Product size: 615*215*536(mm)
Net weight: 30.6KG
产品特征
LED户外3D互动投影灯采用了先进的设计和加工工艺，配合现代感的流线型外型设计，使其外观整齐亮丽;其采用美国芯片，优异的集光设计，使光斑更加均匀，效果好，采用超高透光率镜头，产生柔密、明亮的光束，产生水纹效果逼真，
控制方式:支持网络、RS232及DMX512灯光等多方式联动控制，可实现与灯光控台无缝接入控制，也可配置与中控设备联控。支持定时全自动开关机，定时播放内容。可定时穿插多媒体广告图片、动画视频播放。免费提供50套以上常规互动视频。专业性一体化系统设计， 实现只需接入电源整套设备便可全自动运行。响应速度达到60帧每秒，并支持TUIO协议
输入:DVI-D、HDMI、DP、RGB、Video、Audio
输出: Monitorout、Audioout
宽高比:4:3
数字梯形校正:垂直: +/- -40%;水平: +/-30%
水平扫描频率: 15~91kHz
垂直扫描频率; 24-120
Hzproduct featuresLEDoutdoor 3D interactive projection lamp adopts advanced design andprocessing technology, with modern streamlined appearance design, making itsappearance neat and beautiful; ils American chip, excellent light olleciono design,make the spot more uniform and good effect Ultra-high transmitance lens produces a soft, bright beam that produces water The effect is realistic,Control mode: support multi-mode linkage control such as network, RS232 andDMX512 lighig, which can realize seamless access control with ighting console,andcan also be configured to be ontrolled with central control equipment Supporttimed automatic swichmachine to play content regularfy. You can regularyinsentmultimedia advertisement pictures and animation video playback Free of chargeMore than5Osets of regular ineractive videos. The prfessional integrated systemdesignenables ulautomatic operationby simply plugging inthe power supply.Response speedf 60 frames per second, and support TUIO protocol
Input DVI-D, HDMI, DP, RGB, Video, Audio
Oưtpưt: Monitor out,
AudiooutAspect ratio: 4:3
Digtal Keystone Correction: Verical: +/- -40%; Horizontal: +/ -30%
Horizontal scanning frequency: 15 -91kHz
Verical scanning frequency: 24~120Hz
